Dome Bolt
Dome Bolts (Mushroom Head)
Our Dome Bolts (Mushroom Head Bolts) feature a smooth, rounded top profile designed for safety and aesthetics. The low-profile head eliminates sharp edges, making them ideal for public infrastructure, playground equipment, and architectural paneling where snagging must be prevented. Available with various drive types including Hex Socket and Slotted, or with a square neck for anti-rotation.
Technical Specifications
| Head Style | Dome / Mushroom / Low Profile Button Head |
|---|---|
| Drive Type | Hex Socket (Allen), Slotted, Square Neck, or Tamper-Proof |
| Thread Type | Metric Coarse, Metric Fine, UNC, UNF |
| Size Range | M3 to M24 | 1/8” to 1” Diameter |
| Length | 10 mm to 150 mm |
| Standards | ISO 7380, DIN 603 (Carriage Type), ANSI B18.3 |
| Materials | Stainless Steel (304, 316), Carbon Steel, Brass, Aluminum |
| Finish | Mirror Polished, Zinc Plated (Blue/Black), Chrome Plated |
Key Features & Applications
- Snag-Free Safety Design
- Architectural Cladding
- Playground & Gym Equipment
- Aesthetic Finish
- Automotive Bodywork
- Furniture Assembly
- Vandal Resistant Options
- Conveyor Systems
